| Trade Name | CH |
|---|---|
| Main Type | Main Breaker |
| Interrupting Capacity (A) | 10,000 |
| Phase | 3 |
| Wire | 4 |
| Main Ampere Rating (A) | 200 |
| Voltage Rating | 208Y/120VAC or 240VAC |
| Enclosure Type | NEMA 1 (Indoor) |
| Enclosure Meterial | Metallic |
| Main Breaker | CC 10 kAIC |
| Max. Number 3/4" Poles | 42 |
| Neutral | Insulated/Bondable Neutral |
| Mounting Type | Plug-In |
| Cover | Sold Separately |
| Cover Type (Combination) | CH8LF |
| Cover Type (Surface) | CH8LS |
| Bus Material | One-Piece Silver Flash Plated Copper Bus |
| Grounding Bar | Sold Separately |
| Notes | Furnished with hub closure plates |
| Wire Size | Cu/Al #2/0 - 300 kcmil |
