Cutler-Hammer, BR Loadcenter, 3BR1224B100
| Specification | |
| |
| Trade Name | BR |
| Main Type | Main Breaker |
| Interrupting Capacity (A) | 10,000 |
| Phase | 3 |
| Wire | 4 |
| Main Ampere Rating (A) | 100 |
| Voltage Rating | 208Y/120VAC or 240VAC |
| Enclosure Type | NEMA 1 (Indoor) |
| Enclosure Meterial | Metallic |
| Main Breaker | BR 10 kAIC |
| Number of 1" Spaces | 12 |
| Max. Number of Circuits | 24 |
| Neutral | Insulated/Bondable Neutral |
| Mounting Type | Plug-In |
| Cover | Combination-Surface/Flush |
| Bus Material | Tin Plated Aluminum |
| Grounding Bar | Sold Separately |
| Wire Size | Cu/Al #4 - 1/0 |
| Height (In.) | 21.00 |
| Width (In.) | 14.31 |
| Depth (In.) | 3.88 |
| Standards | UL Listed |
| Warranty | 5 Year Limited |
Downloads
Required Products
Eaton's Cutler-Hammer, Circuit Breaker, BR240 - Brand New
Cutler-Hammer
2 Pole, 40A, Plug-in, 120/240 VAC, Type BR Standard Circuit Breaker, Replacement breaker for Westinghouse, Challenger, Bryant panel
$16.30 2 Pole, 40A, Plug-in, 120/240 VAC, Type BR Standard Circuit Breaker, Replacement breaker for Westinghouse, Challenger, Bryant panel
|
Eaton's Cutler-Hammer, Circuit Breaker, BR360 - Brand New
Cutler-Hammer
3 Pole, 60A, Plug-in, 240 VAC, Type BR Standard Circuit Breaker
$88.41 3 Pole, 60A, Plug-in, 240 VAC, Type BR Standard Circuit Breaker
|
Eaton's Cutler-Hammer, Circuit Breaker, GFCB130 - Brand New
Cutler-Hammer
1 Pole, 30A, Plug-in, 120 VAC, Type GFCB Ground Fault Circuit Breaker, Replacement breaker for Westinghouse, Challenger, Bryant panel
$66.60 1 Pole, 30A, Plug-in, 120 VAC, Type GFCB Ground Fault Circuit Breaker, Replacement breaker for Westinghouse, Challenger, Bryant panel
|
Eaton's Cutler-Hammer, Circuit Breaker, BR120ST - Brand New
Cutler-Hammer
1 Pole, 20A, Plug-in, 120/240 VAC, Type BR Shunt Trip Circuit Breaker
$108.76 1 Pole, 20A, Plug-in, 120/240 VAC, Type BR Shunt Trip Circuit Breaker
|
Eaton's Cutler-Hammer, Circuit Breaker, BR220 - Brand New
Cutler-Hammer
2 Pole, 20A, Plug-in, 120/240 VAC, Type BR Standard Circuit Breaker, Replacement breaker for Westinghouse, Challenger, Bryant panel
$16.30 2 Pole, 20A, Plug-in, 120/240 VAC, Type BR Standard Circuit Breaker, Replacement breaker for Westinghouse, Challenger, Bryant panel
|
Eaton's Cutler-Hammer, Circuit Breaker, BR2020 - Brand New
Cutler-Hammer
1 Pole, 20A/20A, Plug-in, 120 VAC, Type BRD Duplex Circuit Breaker, Replacement breaker for Westinghouse, Challenger, Bryant panel
$24.70 1 Pole, 20A/20A, Plug-in, 120 VAC, Type BRD Duplex Circuit Breaker, Replacement breaker for Westinghouse, Challenger, Bryant panel
|
Eaton's Cutler-Hammer, Circuit Breaker, BR320 - Brand New
Cutler-Hammer
3 Pole, 20A, Plug-in, 240 VAC, Type BR Standard Circuit Breaker
$76.62 3 Pole, 20A, Plug-in, 240 VAC, Type BR Standard Circuit Breaker
|
